ESD L-type Ground Plug

Application

Widely used in electronics cleanrooms, SMT and PCB workshops, semiconductor factories, optical and display workshops, new energy workshops, electronic assembly and repair workstations and other ESD-controlled areas.

Features

• 90° L-shaped Elbow Design Right angle structure, reduces protruding space on the workbench, prevents accidental pulling and disconnection of the ground wire.

• Stable Conductive Contact Metal conductive contact part, good conductivity, ensures continuous static discharge path between ESD table mat and ground wire.

• Durable Insulation Housing High-strength plastic shell, wear-resistant, anti-aging, not easy to crack under frequent plugging and unplugging.

• Standard 4mm Banana Jack Interface Compatible with common 4mm banana plug ESD grounding wires, easy assembly and interchangeability.

• Embedded Installation on ESD Table Mat Can be firmly pressed into the reserved hole of ESD table mat, tight fit and not easy to fall out.

• Easy & Fast Installation Simple operation, no special tools required for installation on ESD mat.

Usage Instructions

1. Punch a matching hole at the designated grounding position of the ESD table mat.
2. Press the L plug into the hole of ESD mat until it is fully seated and secured.
3. Insert the 4mm banana plug of ESD grounding wire into the L plug jack.
4. Connect the other end of grounding wire to reliable ESD earth ground.
5. Check the connection regularly to ensure no loose contact. Replace if metal contact is oxidized or shell cracked.
